Find Your Blue Ox Baseplate and Combo Kits







Blue Ox BX2163 Baseplate Fits 1999-2004 Ford F-350 Super Duty, 1999-2004 Ford F-250 Super Duty, 2000-2004 Ford Excursion

Blue Ox BX2163 Baseplate Fits 1999-2004 Ford F-350 Super Duty, 1999-2004 Ford F-250 Super Duty, 2000-2004 Ford Excursion Blue Ox baseplates are vehicle specific brackets providing attachment points for you Blue Ox tow bar. The baseplate is integrated into the individual bumper design of the towed vehicle, providing a solid, durable connection between your towing vehicle and your towed vehicle (dinghy). Many Blue Ox baseplates have removable tabs that further enhance the aesthetics. When you aren't towing, just remove the tabs.
Manufacturer: Blue Ox
Availability: 100 in stock
SKU: 14-5431
Manufacturer part number: BX2163
Free shipping
$592.99

Product Details

Blue Ox baseplates are easy on your suspension and even easier on the eye, because they are designed with hidden reinforcements. Vehicle specific baseplate is integrated into the individual bumper design of the towed vehicle. When you aren't towing, just remove the tabs to make your baseplate virtually invisible.
Removable Tabs included.

Towed Vehicle ElectricalBrake System & Receiver and Tow Bar Locks are sold separately.

Baseplates are custom designed for each vehicle, bolting directly into the chassis.
Uses as many attachment points as possible.
Most Blue Ox baseplates feature removable tabs that leave a clean look when the vehicle is not being towed.

  • Requires no welding
  • Baseplates are hidden beneath the vehicle body
  • All baseplates are backed by a three year limited warranty

Important Towability Note: Blue Ox offers the above baseplate for your vehicle, but how that vehicle is equipped (i.e. automatic transmission, 4-wheel drive, etc.) must be considered when determining its towability. Please read the owner's manual and/or consult your dealer to determine if your vehicle is flat towable and the correct towing procedures for your vehicle. Additional equipment such as a transmission pump or driveshaft disconnect may be required and are sold separately. Failure to comply with these requirements may result in damage to the towed vehicle or personal injury.



Specifications

Specifications
BRAND Blue Ox
BASEPLATE INSTALL TIME 2 hours
TAB TYPE Standard
TAB HEIGHT 25 inch
TAB WIDTH 28-3/8 inch
SUGGESTED WIRING BX8869

Instructions

CLICK HERE

Compatibility
